Workstation
| Component | Requirements |
|---|---|
| Operating system | Windows 11 Pro |
| AutoCAD® Version(1) | for imos CAD version only: Not required for imos CAD iX OEM - Correct AutoCAD OEM Version supplied with this version. AutoCAD® 2026 (iX2025) AutoCAD® 2024 (iX2023), AutoCAD® 2022 (iX2021), AutoCAD® 2020 (iX2019) |
| SQL Version (For standalone environment) | SQL 2022 Required for iX2025. SQL 2022 (Default for iX 2023). SQL 2019 (For iX 2021) (note SQL Express 2022 is supplied with iX2023/iX2025) SQL Express has a 10GB database size limit. If the database is larger then SQL Standard edition must be purchased. |
| Processor | 3,50 GHz or above recommended. (Suggest Intel Core i7/i9 13th Generation or newer) |
| Main memory | 32 GB Minimum |
| Graphic cards | NOT ONBOARD GRAPHICS - So an Nvidia RTX A2000 or faster, or a Fast Geforce dedicated Graphics Card |
| Screen resolution | Minimum 1920 x 1080 Pixel (Full HD) - 2K 2560x1440 Recommended. 2 monitors also recommended. |
| Storage capacity | min 250 GB free, M.2 / SSD (Solid State Drive) hard disk drive |
| Network card | 1 Gigabit connection |
| Communication | USB headset with Noise cancelling Microphone required for Support calls to in3D |
| Internet connection | Fibre internet for online support or remote working. |
Server
During installation/use of Microsoft® SQL Server® 2022 Express the following minimal conditions apply:
| Component | Requirement |
|---|---|
| Operating system | WindowsServer2016® 64Bit Windows Server 2019® / 2022® 64 Bit or newer |
| SQL Version | SQL 2022 Required for iX2025. SQL 2022 (Default for iX 2023). SQL 2019 (For iX 2021) (note SQL Express 2022 is supplied with iX2023/iX2025) SQL Express has a 10GB database size limit. If the database is larger then SQL Standard edition must be purchased. |
| Processor | x64 Processor: AMD Opteron, AMD Athlon 64, Intel Xeon with Intel EM64T support Intel Pentium IV with EM64T support Processor speed: 2,0 GHz or higher |
| Main memory | min. 8 GB |
| Hard disk | M.2/SSD/SCSI/RAID (Fast read write highly recommended) |
| Storage capacity | Ideally 2+ TB free space for Data |
| Network card | 1 Gigabit connection |
For a full version of Microsoft® SQL Server® the necessary minimum requirements of the Server Edition must be respected.
